Product Details:
Place of Origin: Shaanxi, China
Brand Name: Hoan
Certification: ISO9001:2015 Certificate
Payment & Shipping Terms:
Minimum Order Quantity: 4 pieces
Price: $171.00/pieces 4-199 pieces
Contact Now
Detailed Product Description
Applicable Industries: Translocation Weight (KG): 1.5
Showroom Location: None Video Outgoing-inspection: Provided
Machinery Test Report: Provided Marketing Type: Hot Product 2023
Warranty: Unavailable Core Components: Wirerope
Material: Aluminum Or Stainless Steel Application: Sensor, Transport, Container, Launcher, Shipbuilding
Highlight:

Heavy Duty Wire Rope Shock Mounts

,

Wire Rope Shock Mounts Sensor

,

Heavy Duty Shock Mounts

Seismic Sensor Transport Container Launcher Shipbuilding Shock Vibration Insulation JGX-1276D-220B Wire Shock Absorber

Product Description

Wire shock absorbers are comprised of stainless steel stranded cable threaded through aluminum or stainless steel retaining bars that are mounted for effective shock and vibration isolation.

With their corrosion resistant, all-metal construction, Xi’an Hoan’s wire shock absorbers are environmentally stable, high-performance shock and vibration isolators that are unaffected by temperature extremes, chemicals, oils, ozone and abrasives.



JGX-1276D-220B is the new designed 6 loops 12.7mm diameter model with max static load of 220kg, especially used in any instruments or systems for noise attenuation. With stainless steel material, this model has perfect performance of water-proof, anticorrosion as well as durability.



The JGX-1276D-220B model is now widely used in the field of vehicles, armored cars, launcher, highway transportation, marine, shipbuilding, energy, photographic equipment, aerial equipment, communication apparatus, electronic sensing devices, mobile electronic devices, cameras or any other needed working conditions.

Technical Parameter
  • Model Number Code Ordering of JGX-1276D-220B:Heavy Duty Wire Rope Shock Mounts Seismic Sensor Transport Container Launcher Shipbuilding 0
  • Structural Diagram of JGX-1276D-220B:Heavy Duty Wire Rope Shock Mounts Seismic Sensor Transport Container Launcher Shipbuilding 1
  • Dimension of JGX-1276D-220B:Heavy Duty Wire Rope Shock Mounts Seismic Sensor Transport Container Launcher Shipbuilding 2
  • Mounting Options of JGX-1276D-220B:Heavy Duty Wire Rope Shock Mounts Seismic Sensor Transport Container Launcher Shipbuilding 3
  • Compression of JGX-1276D-220B:Heavy Duty Wire Rope Shock Mounts Seismic Sensor Transport Container Launcher Shipbuilding 4
  • 45° Compression of JGX-1276D-220B:Heavy Duty Wire Rope Shock Mounts Seismic Sensor Transport Container Launcher Shipbuilding 5
  • Shear/Roll of JGX-1276D-220B:Heavy Duty Wire Rope Shock Mounts Seismic Sensor Transport Container Launcher Shipbuilding 6
Mounting Bars

Material of Mounting Bars *
   Stainless Steel or Aluminum can be selected

* Surface Treatment Selection of Aluminum Mounting Bars *

  • White Anodizing: The surface treatment to make the aluminum surface harder than itself. The color of the white anodized aluminum mounting bars keep the same color as the aluminum itself. It is the normal surface treatment of the aluminum mounting bars;
  • Hard Anodizing: The surface treatment to make the aluminum mounting bars much more harder than the white anodized way. The color of the hard anodized aluminum mounting bars is more darker than the white anodizing way. Special use for complex or special requirements of the working conditions of the using of wire rope isolators.
Characteristics

* Unique Characteristics of Xi'an Hoan's Vibration Isolators *

  • No creep or ageing.
  • High internal damping.
  • Very wide temperature range.
  • Wide variety of possible fittings.
  • Rapid and economical prototyping.
  • Extremely rugged construction and long lifespan.
  • Excellent combined shock and vibration isolation.
  • Not affected by chemical agents, seawater, ozone, UV rays,...
Applications

* Applications of Wire Rope Isolators *



Applications

Typical Equipment

Protection From

Operational Advantages

Shipboard

Electronics, Computers,
Machinery

Explosive blast,
Inherent vibration, Storms

Long life, Maintenance-free,
Temperature extremes,
Corrosion resistance,
All axes protection

Rough Terrain Vehicles

Instrumentation, Generators,
Electronics

Rough terrain,
Poor road conditions,
Collision

Long life, Maintenance-free,
Temperature extremes, Ozone,
Radioactivity, UV Radiation

Aircraft

Electronics, Computers

High-G maneuvering,
Hard landings, Turbulent air

Temperature and altitude extremes, Lightweight

Shipping Containers

Optics, Instruments, Missiles, Electronics

Transit, Handling drop,

Loading/Unloading

Long life, Maintenance-free,

Exposure to moisture, Repeated use

Industrial Equipment



Centrifuge, Dryers, Pumps

Unbalanced dynamic loads,

Fluid hammer, Inherent vibration, Foundation weakness

Long life, Maintenance-free,

Corrosive environments

Ordnance Equipment

Missile launchers, Tank

artillery, Computer controls, Electronics

Rough terrain, Railroad humping, Transit

Maintenance-free, Temperature extremes, Nearby blast

Medical Equipment

Mechanical equipment

necessary for patient care

Vibration from moving parts, Mobile carts-Transport shock

Maintenance-free, No out gassing, Can be sterilized

Chimneys

Chimneys, Scrubbers,

Measuring devices

Wind causing resonant

frequencies, Stack gas causing turbulence near scrubber, etc.

Maintenance-free, Temperature extremes, Corrosive environments



* Applications Show *

Heavy Duty Wire Rope Shock Mounts Seismic Sensor Transport Container Launcher Shipbuilding 7



Heavy Duty Wire Rope Shock Mounts Seismic Sensor Transport Container Launcher Shipbuilding 8



Heavy Duty Wire Rope Shock Mounts Seismic Sensor Transport Container Launcher Shipbuilding 9



Heavy Duty Wire Rope Shock Mounts Seismic Sensor Transport Container Launcher Shipbuilding 10



Heavy Duty Wire Rope Shock Mounts Seismic Sensor Transport Container Launcher Shipbuilding 11



Heavy Duty Wire Rope Shock Mounts Seismic Sensor Transport Container Launcher Shipbuilding 12



Heavy Duty Wire Rope Shock Mounts Seismic Sensor Transport Container Launcher Shipbuilding 13





Company Information

Xi’an Hoan Mirowave Co. Ltd., the professional manufacture of vibration isolators and mounts, provides top quality energy absorption and vibration isolation solutions to a variety filed of defense, commercial and heavy industry.



Our products cover a wide range, which are not only vibration isolators, vibration mounts, friction dampers and also shock absorbers as well as LC filters. Established in 2005, with the fast development of decades, we have been grew with more than 500 employees including more than 100 experts.



Now, we are the best seller for more than 31 provinces in China and almost 25 oversea countries for areas of motor, fans, punch machine, elevator, compressor, chemical equipment, subway train, bridge, mechanical equipment, large scaled construction, studios, theaters, vehicles, vessels, and machines.



Contact us today to see how our products can benefit your specific equipment application needs or alternatively you may find one of our many representatives to help you meet your product requirements!
