Place of Origin:
Shaanxi, China
Brand Name:
Hoan
Certification:
ISO9001:2015
Model Number:
JZP-3.2
JZP Series
As early as the 60s of the 20th century, the concept of shock absorption has been introduced into the construction of buildings, water conservancy and mining. Contact stresses, friction, and vibration attenuation of temporary and fixed structures have a profound impact on the stability performance of buildings and facilities.
In view of the diversity of damping principles and the arduousness of analyzing the stress and deformation states at the joints of components, it is quite challenging to mathematically model the damping phenomena of structures.
At present, this kind of JZP-3.2 shock absorbing equipment is widely used in high-end medical instrument systems, deep-sea exploration, submarines, on-board electronics, control cabinets, etc.
Deep-sea exploration equipment also has extremely high requirements for shock absorption. In the deep-sea environment, the detection equipment is exposed to a variety of factors, such as huge water pressure, complex water currents, and vibrations generated during its own operation. The JZP-3.2 damping device is installed inside these equipment, which can reduce the impact of the equipment's own vibration on the detection accuracy when the equipment is operated by the thruster and the detection instrument is used for data acquisition. At the same time, in the face of complex water currents in the deep sea, it can also prevent damage to the delicate components inside the equipment through its own unique shock absorption mechanism.
With the continuous development of science and technology, the requirements for shock absorbers are also increasing. In the future, JZP-3.2 shock absorber is expected to make greater breakthroughs in intelligence and adaptation to adapt to more complex working environments and more sophisticated equipment needs.
Structure Drawing
Technical Parameter Table
| Technical Parameter | JZP-5.0B | JZP-3.2 | JZP-5.2 | JZP-7.5 |
| Pz Nominal Load (kg) | 5.0 | 3.2 | 5.2 | 7.5 |
| Deflection | Downward Pressure | |||
| Deformation Displacement (mm) | ≤0.3 | |||
| Resonant Frequency (Hz) | 35±3 | |||
| Working Temperature (℃) | -45～+65 | |||
| Shock (Ks) |
100g6ms |
|||
| Peak Response G | ≤3.6Kms2 | |||
| Vibration (Kv) | Accord with National Military Standard GJB150-16 | |||
Impact & Vibration Curve
* Unique Characteristics of Xi'an Hoan's Vibration Isolators *
* No creep or ageing.
* High internal damping.
* Very wide temperature range.
* Wide variety of possible fittings.
* Rapid and economical prototyping.
* Extremely rugged construction and long lifespan.
* Excellent combined shock and vibration isolation.
* Not affected by chemical agents, seawater, ozone, UV rays
