JZP-3.2-SC1 Rubber Shock Absorber for High-Precision Measuring Instruments and Analytical Equipment

JZP-3.2-SC1 Rubber Shock Absorber for High-Precision Measuring Instruments and Analytical Equipment

High Precision Rubber Shock Absorber

Analytical Equipment Rubber Shock Absorber

Measuring Instruments Rubber Shock Absorber

Place of Origin:

Shaanxi, China

Brand Name:

Hoan

Certification:

ISO9001:2015

Model Number:

JZP-3.2-SC1

Contact Us
Request A Quote
Product Details
Installation Method:
Bolt-on
Design Style:
Industrial
Application:
Automotive, Industrial, Machinery
Height:
50mm
Max Static Load:
20-47N(2kg-4.8Kg)
Product Load Capacity:
Customizable
Easy Installation:
Simple And Easy To Install
Temperature Resistance:
Yes
Overall Width:
58mm
Spring Rate:
100-1000 Lbs/in
Isolation Efficiency:
90%
Item Number:
033
Corrosion Resistance:
Highly Resistant To Corrosion
Shape:
Cylindrical
Size:
Various Sizes Available
Highlight:

High Precision Rubber Shock Absorber

,

Analytical Equipment Rubber Shock Absorber

,

Measuring Instruments Rubber Shock Absorber

Payment & Shipping Terms
Minimum Order Quantity
4 piences
Delivery Time
7
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
4,pience,7
Product Description

JZP-SC1 Series

Xi'an Hoan Microwave Co., Ltd.'s JZP series friction damping vibration isolator is a high-performance vibration isolation product with many significant features and advantages.



These isolators are designed and made of advanced materials, usually a combination of metal and rubber. It uses the interaction between metal and rubber and the special friction damping principle to achieve efficient vibration isolation and energy dissipation, with good impact resistance, which can effectively buffer the vibration and impact generated during the operation of the equipment and protect the equipment from damage.



JZP series friction damping isolators have a wide range of applications. In the aerospace field, various precision electronic equipment and navigation instruments on the aircraft need vibration isolators to resist vibration interference during flight, and JZP series vibration isolators can ensure the stability of these equipment and ensure flight safety. In the communication industry, microwave equipment and optical fiber transmission equipment in communication base stations are very sensitive to vibration, and the vibration isolator can ensure the stable transmission of communication signals and improve communication quality. In the scientific research laboratory, those high-precision measuring instruments and analytical equipment rely on JZP series vibration isolators to create a stable working environment, so as to improve the accuracy of experimental data.



With its advanced technology, excellent performance and wide application prospects, the JZP series friction damping vibration isolator of Xi'an Hoan Microwave Co., Ltd. has become an ideal choice for equipment vibration isolation in many industries.



Product dimensions

JZP-3.2-SC1 Rubber Shock Absorber for High-Precision Measuring Instruments and Analytical Equipment 0

Series

D

(mm)

H±1

(mm)

h

(mm)

A±0.2

(mm)

B

(mm)

d d2 R

b

(mm)

h1

(mm)

JZP-SC1 60 36 21.7 50 60 M5 Φ5.5 5 28 3.4



Product parameters

JZP-3.2-SC1 Rubber Shock Absorber for High-Precision Measuring Instruments and Analytical Equipment 1

JZP-3.2-SC1 Rubber Shock Absorber for High-Precision Measuring Instruments and Analytical Equipment 2

Model

Nominal Load

(KG)

Deflection

Working Temperature

(℃)

Resonant Frequency

(Hz)

Damping ratio Impact test

Expiration date

(year)

JZP-3.2-SC1 3.2 ≤0.3 -45~+65 41.5±5 ≥0.13 100G12次 8
JZP-4.2-SC1 4.2
JZP-5.2-SC1 5.2
JZP-6.0-SC1 6.0
JZP-7.0-SC1 7.0
JZP-7.5-SC1 7.5
JZP-9.0-SC1 9.0
JZP-10.5-SC1 10.5
JZP-13.5-SC1 13.5
JZP-15-SC1 15
