JZP-9.0-SC1 Friction Damping Vibration Isolator The Top Choice for Vibration Isolation in Microwave Communication Devices

JZP-9.0-SC1 Friction Damping Vibration Isolator The Top Choice for Vibration Isolation in Microwave Communication Devices

Friction Damping Vibration Isolator

JZP-9.0-SC1 Vibration Isolator

Microwave Communication Devices Vibration Isolator

Place of Origin:

Shaanxi, China

Brand Name:

Hoan

Certification:

ISO9001:2015

Model Number:

JZP-9.0-SC1

Contact Us
Request A Quote
Product Details
Features:
Anchoring Holes; Oil Resistant
Load Range:
5,6KG
Mounting Hole Size:
8mm
Pressure Range:
High
Drawing Format:
DWG And PDF
Temperature Range:
-40°C To 100°C
Installation Type:
Horizontal/Vertical
Usage:
Reduce Vibration And Noise
Resonance Frequency:
40 Hz
Corrosion Resistance:
Yes
Width:
60mm
Easy Installation:
Simple And Easy To Install
Compression Ratio:
1.2:1
Shape:
Cylindrical
Highlight:

Friction Damping Vibration Isolator

,

JZP-9.0-SC1 Vibration Isolator

,

Microwave Communication Devices Vibration Isolator

Payment & Shipping Terms
Minimum Order Quantity
4 piences
Delivery Time
7
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
4,pience,7
Product Description

JZP-SC1 Series

The JZP series friction damping vibration isolator of Xi'an Hongan Microwave Co., Ltd. is a product with excellent performance and wide application value in the field of vibration isolation.


JZP series friction damping isolator is unique in structural design. It consists of several key components that work together to achieve vibration isolation. The core principle is based on the frictional damping effect, which creates friction between the friction elements inside the isolator when the device is subjected to vibrations. This friction can effectively dissipate vibration energy, thereby preventing the transmission of vibration waves and achieving the purpose of vibration isolation. Compared to traditional vibration isolators, this frictional damping-based method of operation enables the JZP series vibration isolators to exhibit stable vibration isolation performance when dealing with vibrations of different frequencies and amplitudes.



In different working environments, JZP series vibration isolators show good stability. It retains its vibration isolation performance in environments with large temperature variations and in the presence of certain mechanical shocks. Its structural design ensures the reliability of the internal friction elements and does not cause large fluctuations in performance due to environmental factors.



In the field of microwave communication, the stability of communication equipment is crucial to the quality of signal transmission. JZP series friction damping vibration isolator can effectively isolate the influence of external vibration on microwave communication equipment, ensure the stable transmission of signals, reduce signal interruption and bit error rate, and improve the overall performance of communication systems.



Product dimensions

JZP-9.0-SC1 Friction Damping Vibration Isolator The Top Choice for Vibration Isolation in Microwave Communication Devices 0

Series

D

(mm)

H±1

(mm)

h

(mm)

A±0.2

(mm)

B

(mm)

d d2 R

b

(mm)

h1

(mm)

JZP-SC1 60 36 21.7 50 60 M5 Φ5.5 5 28 3.4



Product parameters

JZP-9.0-SC1 Friction Damping Vibration Isolator The Top Choice for Vibration Isolation in Microwave Communication Devices 1

JZP-9.0-SC1 Friction Damping Vibration Isolator The Top Choice for Vibration Isolation in Microwave Communication Devices 2

Model

Nominal Load

(KG)

Deflection

Working Temperature

(℃)

Resonant Frequency

(Hz)

Damping ratio Impact test

Expiration date

(year)

JZP-3.2-SC1 3.2 ≤0.3 -45~+65 41.5±5 ≥0.13 100G12次 8
JZP-4.2-SC1 4.2
JZP-5.2-SC1 5.2
JZP-6.0-SC1 6.0
JZP-7.0-SC1 7.0
JZP-7.5-SC1 7.5
JZP-9.0-SC1 9.0
JZP-10.5-SC1 10.5
JZP-13.5-SC1 13.5
JZP-15-SC1 15



* Unique Characteristics of Xi'an Hoan's Vibration Isolators *

* No creep or ageing.
* High internal damping.
* Very wide temperature range.
* Wide variety of possible fittings.
* Rapid and economical prototyping.
* Extremely rugged construction and long lifespan.
* Excellent combined shock and vibration isolation.
* Not affected by chemical agents, seawater, ozone, UV rays



laboratory
