JZP-3.5B-SC Modular Rubber Shock Absorber with 5-6KG Load Range 1:2 Compression Ratio and 40g/11ms Shock Resistance

Name: JZP-3.5B-SC Modular Rubber Shock Absorber with 5-6KG Load Range 1:2 Compression Ratio and 40g/11ms Shock Resistance
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JZP-3.5B-SC
Availability: InStock

Brand Name:	Hoan
Model Number:	JZP-3.5B-SC
MOQ:	4
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Shape:

Cylindrical

Load Range:

5，6KG

Compatibility:

Fits Most Vehicles And Equipment

After Warranty Service:

Online Support

Installation Method:

Bolt-on Or Screw-on

Weight:

0.2kg

Performance:

Shockproof

Compression Ratio:

1:2

Relative Product:

Backdraft Damper

Shock Resistance:

40g/11ms

Temperature Resistance:

Can Withstand Extreme Temperatures

Warranty:

1 Year

Showroom Location:

None

Max Static Load:

20-47N(2kg-4.8Kg)

Uv Resistance:

Strong

Highlight:

5-6KG Load Range Rubber Shock Absorber

1:2 Compression Ratio Vibration Isolator

40g/11ms Shock Resistance Modular Vibration Isolator

Product Description

JZP-3.5B-SC Modular Rubber Shock Absorber

Lightweight Yet High-Strength Vibration Isolator for Limited Load Capacity and Space

The JZP-B-SC Series from Xi'an Hoan Microwave Co., Ltd. represents advanced vibration isolation technology designed specifically for on-vehicle applications where weight and space are critical factors.

Key Features and Design Advantages

Advanced high-performance elastomer materials with excellent elasticity, damping, creep resistance, and fatigue resistance
Computer-Aided Engineering (CAE) optimized topology for maximum strength-to-weight ratio
Modular design ensures easy installation and clear force transmission paths
Effective energy absorption and dissipation through material properties
Lightweight construction without compromising structural integrity

Dimension Parameters

Model	D (mm)	H±1 (mm)	h (mm)	A±0.2 (mm)	B (mm)	d	d2	R	B (mm)
JZP-B-SC	46	30	21	40	50	M4	∅5.5	5	22

Technical Parameters

Model	Nominal Load (kg)	Static Displacement (mm)	Working Temperature (℃)	Resonance Frequency (Hz)	Impact Test	Valid Period (year)
JZP-1.0B-SC	1.0	≤0.3	-45～+65	41.5±5	100G12times	8
JZP-1.5B-SC	1.5
JZP-2.0B-SC	2.0
JZP-2.5B-SC	2.5
JZP-3.0B-SC	3.0
JZP-3.5B-SC	3.5
JZP-4.0B-SC	4.0
JZP-5.0B-SC	5.0
JZP-5.5B-SC	5.5
JZP-6.0B-SC	6.0

Performance Characteristics

Vibration and impact curve of JZP-B-SC Series:

Vibration

Impact
