Place of Origin:
Shaanxi, China
Brand Name:
Hoan
Certification:
ISO9001:2015
Model Number:
JZP-4.2
JZP Series
As early as the 60s of the 20th century, the concept of shock absorption has been introduced into the construction of buildings, water conservancy and mining. Contact stresses, friction, and vibration attenuation of temporary and fixed structures have a profound impact on the stability performance of buildings and facilities.
In view of the diversity of damping principles and the arduousness of analyzing the stress and deformation states at the joints of components, it is quite challenging to mathematically model the damping phenomena of structures.
At present, this kind of JZP-4.2 shock absorbing equipment is widely used in high-end medical instrument systems, deep-sea exploration, submarines, on-board electronics, control cabinets, etc.
In the field of on-board electronics, JZP-4.2 shock absorbers are also widely used. Modern cars are equipped with a large number of electronic devices, such as on-board computers, premium audio systems, etc. During the driving process, the car will be constantly affected by the vibration caused by road bumps, acceleration and deceleration. These vibrations can be very detrimental to the service life and performance of on-board electronics. The KLP-5.3 damping device provides effective damping protection for on-board electronics according to the vibration of the car while driving. For example, when a car is driving on a rough road, the shock absorber responds quickly and reduces the impact of vibration on the electronics.
With the continuous development of science and technology, the requirements for shock absorbers are also increasing. In the future, JZP-4.2 shock absorber is expected to make greater breakthroughs in intelligence and adaptation to adapt to more complex working environments and more sophisticated equipment needs.
Structure Drawing
Technical Parameter Table
| Technical Parameter | JZP-5.0B | JZP-3.2 | JZP-5.2 | JZP-7.5 |
| Pz Nominal Load (kg) | 5.0 | 3.2 | 5.2 | 7.5 |
| Deflection | Downward Pressure | |||
| Deformation Displacement (mm) | ≤0.3 | |||
| Resonant Frequency (Hz) | 35±3 | |||
| Working Temperature (℃) | -45～+65 | |||
| Shock (Ks) | 100g6ms | |||
| Peak Response G | ≤3.6Kms2 | |||
| Vibration (Kv) | Accord with National Military Standard GJB150-16 | |||
Impact & Vibration Curve
* Unique Characteristics of Xi'an Hoan's Vibration Isolators *
* No creep or ageing.
* High internal damping.
* Very wide temperature range.
* Wide variety of possible fittings.
* Rapid and economical prototyping.
* Extremely rugged construction and long lifespan.
* Excellent combined shock and vibration isolation.
* Not affected by chemical agents, seawater, ozone, UV rays
