Name: JMZ-1-3.5A Adjustable Vibration Isolator for HVAC Equipment, 3.5kg Load
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JMZ-1-3.5A
Availability: InStock

Home > products > Spring Isolator >

JMZ-1-3.5A Adjustable Vibration Isolator for HVAC Equipment, 3.5kg Load

HVAC vibration isolator 3.5kg load

adjustable spring isolator for HVAC

JMZ-1-3.5A vibration isolator with warranty

Place of Origin:

China

Brand Name:

Hoan

Model Number:

JMZ-1-3.5A

Request A Quote

Product Details

Installation Method:

Bolted

Warranty:

1 Year

Temperature Range:

-40°F To 180°F

Showroom Location:

None

Adjustability:

Adjustable

Certifications:

UL Listed, RoHS Compliant

Application:

HVAC Equipment

Marketing Type:

New Product 2025

Dimensions:

Various Sizes Available

Mounting Type:

Top Plate

Model:

JMZ-1-3.5A

Condition:

New

Machinery Test Report:

Not Available

Type:

Vibration Isolator

Highlight:

HVAC vibration isolator 3.5kg load

adjustable spring isolator for HVAC

JMZ-1-3.5A vibration isolator with warranty

Payment & Shipping Terms

Minimum Order Quantity

Payment Terms

L/C,D/A,T/T,Western Union,D/P,MoneyGram

JMZ-1-3.5A Adjustable Vibration Isolator for HVAC Equipment, 3.5kg Load

Get Best Price

Stainless Steel Wire Rope Vibration Isolator 2kg Load Capacity

Get Best Price

JMZ-1-1.5A Wire Rope Vibration Isolator 44mm for Industrial Engine Mounts

Get Best Price

JMZ-1-1.0A Friction Damping Vibration Isolator 1.0KG Load Capacity

Get Best Price

86-29-88292913

Contact Now

Product Description

JMZ-1-3.5A Friction Damping Vibration Isolator for Precision Equipment

JMZ Series: Addressing Environmental Pain Points in Precision Manufacturing

In precision machining, optical inspection, semiconductor manufacturing, and microscale scientific research, environmental micro-vibrations can significantly impair equipment precision and product yield rates. The JMZ Friction Damping Vibration Isolator from Xi'an Hoan Microwave Co., Ltd. provides an effective solution for these critical industry challenges.

With highly efficient damping characteristics, the JMZ isolator significantly attenuates broadband vibrations from floor transmission, nearby traffic, or internal mechanical equipment—particularly challenging mid-to-low frequency disturbances. Placing precision instruments on the JMZ vibration isolation platform creates a "dynamic stability zone" that suppresses platform resonance and ensures accuracy and repeatability in machining, measurement, and observation processes.

Dimension Parameters

Model	Nominal Load (kg)	B	A±0.2	H	h±0.5	T	d	d1	D
JMZ-1-1.0A	1.0	44	35	50	36	SW14	M5-7H	5.1～5.4	39.5
JMZ-1-1.5A	1.5	Same as JMZ-1-1.0A except nominal load
JMZ-1-2.0A	2.0	Same as JMZ-1-1.0A except nominal load
JMZ-1-3.0A	3.0	Same as JMZ-1-1.0A except nominal load
JMZ-1-3.5A	3.5	Same as JMZ-1-1.0A except nominal load

Performance Characteristics

Model	Pz Nominal Load (KG)	Pz Max Deflection (mm)	Vibration (Kv)	Shock (Ks)	Resonant Frequency (Hz)	Working Temperature(℃)
JMZ-1-1.0A	1.0	3±1.5	≤3.5	30g/11ms	＜15	-65～+120
JMZ-1-1.5A	1.5	Same as JMZ-1-1.0A except nominal load
JMZ-1-2.0A	2.0	2±1.5	Same as JMZ-1-1.0A except noted parameters
JMZ-1-3.0A	3.0	3±1.5	Same as JMZ-1-1.0A except noted parameters
JMZ-1-3.5A	3.5	Same as JMZ-1-1.0A except nominal load

Unique Characteristics

No creep or ageing
High internal damping
Very wide temperature range (-65℃ to +120℃)
Wide variety of possible fittings
Rapid and economical prototyping
Extremely rugged construction and long lifespan
Excellent combined shock and vibration isolation
Resistant to chemical agents, seawater, ozone, and UV rays

Application Examples
