Product Details:
Place of Origin: Shaanxi, China
Brand Name: Hoan
Model Number: GR5
Payment & Shipping Terms:
Minimum Order Quantity: 4 pieces
Price: $25.00/pieces 4-99 pieces
Contact Now
Detailed Product Description
Mateiral: Stainless Steel Or Aluminum Certificate: ISO 9001:2015
Application: Helicopter Drone, Camera Crane, UAV Camera
Highlight:

ISO9001 wire rope vibration isolator

,

wire rope vibration isolator Shock

,

Shock Isolation Solutions

UAV Camera Gimbal Helicopter Drone Crane Stabilizer Shock Vibration Insulation GR5 Aerial Photography Cinema Vibration I

Product Description



Xi'an Hoan's GR5 Series is the best choice for building your own Camera Gimbal Stabilizer!



The GR5 Series cinema vibration isolators is designed especially for single use or building camera gimbals and camera crane to absorb tensional force against the vehicles movement with the camera.



The GR5 series cinema vibration isolators are made by the 4.0mm diameter wire rope winded in the two mounting bars, which has the max static load from 16N (1.63kg) to 80N (8.16kg).



The GR5 Series camera vibration isolators can smooth out the small rhythmic vibrations of a traveling shot as well as dampening those sudden, unexpected jolts that a stone or a pothole can produce. With stainless steel material, the GR5 series isolators have perfect performance of water-proof, anticorrosion as well as durability.



Nowadays, the GR series isolators are used widely in the field of RC car aerial drone systems stabilizer, helicopter drone gimbal stabilizer, video project stabilizer, drone shooting stabilizer, UAV camera and camera stabilizer, etc.

Technical Parameter
  • Model Number Code Ordering of GR5 Series:ISO9001 Wire Rope Vibration Isolator Shock Isolation Solutions 0
  • Structural Diagram of GR5 Series:ISO9001 Wire Rope Vibration Isolator Shock Isolation Solutions 1
  • Dimension of GR5 Series:ISO9001 Wire Rope Vibration Isolator Shock Isolation Solutions 2
  • Mounting Options of GR5 Series:ISO9001 Wire Rope Vibration Isolator Shock Isolation Solutions 3
  • Compression of GR5 Series:ISO9001 Wire Rope Vibration Isolator Shock Isolation Solutions 4
  • 45° Compression of GR5 Series:ISO9001 Wire Rope Vibration Isolator Shock Isolation Solutions 5
  • Shear/Roll of GR5 Series:ISO9001 Wire Rope Vibration Isolator Shock Isolation Solutions 6
Mounting Bars

Material of Mounting Bars *
   Stainless Steel or Aluminum can be selected

* Surface Treatment Selection of Aluminum Mounting Bars *

  • White Anodizing: The surface treatment to make the aluminum surface harder than itself. The color of the white anodized aluminum mounting bars keep the same color as the aluminum itself. It is the normal surface treatment of the aluminum mounting bars;
  • Hard Anodizing: The surface treatment to make the aluminum mounting bars much more harder than the white anodized way. The color of the hard anodized aluminum mounting bars is more darker than the white anodizing way. Special use for complex or special requirements of the working conditions of the using of wire rope isolators.
Characteristics

* Unique Characteristics of Xi'an Hoan's Vibration Isolators *

  • No creep or ageing.
  • High internal damping.
  • Very wide temperature range.
  • Wide variety of possible fittings.
  • Rapid and economical prototyping.
  • Extremely rugged construction and long lifespan.
  • Excellent combined shock and vibration isolation.
  • Not affected by chemical agents, seawater, ozone, UV rays,...
Applications

* Main Applications of Wire Rope Isolators *



Applications

Typical Equipment

Protection From

Operational Advantages

Shipboard

Electronics, Computers,
Machinery

Explosive blast,
Inherent vibration, Storms

Long life, Maintenance-free,
Temperature extremes,
Corrosion resistance,
All axes protection

Rough Terrain Vehicles

Instrumentation, Generators,
Electronics

Rough terrain,
Poor road conditions,
Collision

Long life, Maintenance-free,
Temperature extremes, Ozone,
Radioactivity, UV Radiation

Aircraft

Electronics, Computers

High-G maneuvering,
Hard landings, Turbulent air

Temperature and altitude extremes, Lightweight

Shipping Containers

Optics, Instruments, Missiles, Electronics

Transit, Handling drop,

Loading/Unloading

Long life, Maintenance-free,

Exposure to moisture, Repeated use

Industrial Equipment



Centrifuge, Dryers, Pumps

Unbalanced dynamic loads,

Fluid hammer, Inherent vibration, Foundation weakness

Long life, Maintenance-free,

Corrosive environments

Ordnance Equipment

Missile launchers, Tank

artillery, Computer controls, Electronics

Rough terrain, Railroad humping, Transit

Maintenance-free, Temperature extremes, Nearby blast

Medical Equipment

Mechanical equipment

necessary for patient care

Vibration from moving parts, Mobile carts-Transport shock

Maintenance-free, No out gassing, Can be sterilized

Chimneys

Chimneys, Scrubbers,

Measuring devices

Wind causing resonant

frequencies, Stack gas causing turbulence near scrubber, etc.

Maintenance-free, Temperature extremes, Corrosive environments




* Aerial Photography Camera Gimbal Applications Show*

ISO9001 Wire Rope Vibration Isolator Shock Isolation Solutions 7



ISO9001 Wire Rope Vibration Isolator Shock Isolation Solutions 8



ISO9001 Wire Rope Vibration Isolator Shock Isolation Solutions 9



ISO9001 Wire Rope Vibration Isolator Shock Isolation Solutions 10



ISO9001 Wire Rope Vibration Isolator Shock Isolation Solutions 11



ISO9001 Wire Rope Vibration Isolator Shock Isolation Solutions 12



ISO9001 Wire Rope Vibration Isolator Shock Isolation Solutions 13
