Helicopter Drone UAV Camera Gimbal Aerial Photography Shock Absorption GR2 Wire Rope Damper

Helicopter Drone UAV Camera Gimbal Aerial Photography Shock Absorption GR2 Wire Rope Damper

Place of Origin:

Shaanxi, China

Brand Name:

Hoan

Model Number:

GR2

Contact Us
Request A Quote
Product Details
Type:
Noise And Attenuation
Material:
Stainless Steel Or Aluminum
Certificate:
ISO9001:2015
Application:
Helicopter, Drone, UAV Camera, Cinema
Port:
Xi'an Or Specified
Payment & Shipping Terms
Minimum Order Quantity
4 pieces
Price
$14.00/pieces 4-99 pieces
Packaging Details
Standard export packing or as per customers' requirements.
Supply Ability
1500 Piece/Pieces per Month
Product Description

Choose GR2 series helicopter drone wire dampers to build your own Camera Gimbal!



Xi'an Hoan's GR2 Series wire rope dampers are designed especially for single use or building camera gimbals to absorb tensional force against the vehicles movement with the cameras as well as airborne digital cameras.



There are 4 models included in the GR2 series, which has the max static load from 4.9N (0.50kg) to 12N (1.22kg).



The GR2 Series compact wire rope dampers is made by the 1.6mm diameter wire dampers winded in the two mounting bars, which can smooth out the small rhythmic vibrations of a traveling shot as well as dampening those sudden, unexpected jolts that a stone or a pothole can produce.

Technical Parameter
  • Model Number Code Ordering of GR2 Series:Helicopter Drone UAV Camera Gimbal Aerial Photography Shock Absorption GR2 Wire Rope Damper 0
  • Structural Diagram of GR2 Series:Helicopter Drone UAV Camera Gimbal Aerial Photography Shock Absorption GR2 Wire Rope Damper 1
  • Dimension of GR2 Series:Helicopter Drone UAV Camera Gimbal Aerial Photography Shock Absorption GR2 Wire Rope Damper 2
  • Mounting Options of GR2 Series:Helicopter Drone UAV Camera Gimbal Aerial Photography Shock Absorption GR2 Wire Rope Damper 3
  • Compression of GR2 Series:Helicopter Drone UAV Camera Gimbal Aerial Photography Shock Absorption GR2 Wire Rope Damper 4
  • 45° Compression of GR2 Series:Helicopter Drone UAV Camera Gimbal Aerial Photography Shock Absorption GR2 Wire Rope Damper 5
  • Shear/Roll of GR2 Series:Helicopter Drone UAV Camera Gimbal Aerial Photography Shock Absorption GR2 Wire Rope Damper 6
Mounting Bars

Material of Mounting Bars *
   Stainless Steel or Aluminum can be selected

* Surface Treatment Selection of Aluminum Mounting Bars *

  • White Anodizing: The surface treatment to make the aluminum surface harder than itself. The color of the white anodized aluminum mounting bars keep the same color as the aluminum itself. It is the normal surface treatment of the aluminum mounting bars;
  • Hard Anodizing: The surface treatment to make the aluminum mounting bars much more harder than the white anodized way. The color of the hard anodized aluminum mounting bars is more darker than the white anodizing way. Special use for complex or special requirements of the working conditions of the using of wire rope isolators.
Characteristics

* Unique Characteristics of Xi'an Hoan's Vibration Isolators *

  • No creep or ageing.
  • High internal damping.
  • Very wide temperature range.
  • Wide variety of possible fittings.
  • Rapid and economical prototyping.
  • Extremely rugged construction and long lifespan.
  • Excellent combined shock and vibration isolation.
  • Not affected by chemical agents, seawater, ozone, UV rays,...
Applications

Helicopter Drone UAV Camera Gimbal Aerial Photography Shock Absorption GR2 Wire Rope Damper 7



Helicopter Drone UAV Camera Gimbal Aerial Photography Shock Absorption GR2 Wire Rope Damper 8



Helicopter Drone UAV Camera Gimbal Aerial Photography Shock Absorption GR2 Wire Rope Damper 9



Helicopter Drone UAV Camera Gimbal Aerial Photography Shock Absorption GR2 Wire Rope Damper 10



Helicopter Drone UAV Camera Gimbal Aerial Photography Shock Absorption GR2 Wire Rope Damper 11



Helicopter Drone UAV Camera Gimbal Aerial Photography Shock Absorption GR2 Wire Rope Damper 12



Helicopter Drone UAV Camera Gimbal Aerial Photography Shock Absorption GR2 Wire Rope Damper 13
