Jgx-1598d-428b Aluminum Wire Rope Shock Isolator Condition for Bearing Core Components

Jgx-1598d-428b Aluminum Wire Rope Shock Isolator Condition for Bearing Core Components

Place of Origin:

China

Brand Name:

Hoan

Contact Us
Request A Quote
Product Details
Condition:
New
Applicable Industries:
Energy & Mining
Weight (KG):
0.5
Showroom Location:
None
Video Outgoing-inspection:
Not Available
Machinery Test Report:
Not Available
Marketing Type:
Hot Product 2019
Warranty:
1 Year
Core Components:
Bearing
Payment & Shipping Terms
Minimum Order Quantity
4 pieces
Product Description
Product Description



Wire rope shock isolators are comprised of stainless steel stranded cable threaded through aluminum alloy retaining bars that are mounted for effective shock and vibration isolation.



With their corrosion resistant, all-metal construction, Xi’an Hoan’s wire rope shock isolators are environmentally stable, high-performance shock and vibration isolators that are unaffected by temperature extremes, chemicals, oils, ozone and abrasives.



The JGX-0160D-2.2A wire rope isolator is the kind type isolators from the family JGX-0160 series. The stainless steel cables and retaining bars of the JGX-0160D-2.2A provides amazing vibration isolation any time in use.



JGX-0160D-2.2A is the new designed 10 loops 1.6mm diameter isolators with max static load of 2.2kg, especially used in the precise instruments for the noise attenuation. With stainless steel material, this kind wire rope isolator have perfect performance of water-proof, anticorrosion as well as durability.



The wire rope shock isolators are now widely used in the field of military vehicles, armored cars, missile, launcher, highway transportation, marine, shipbuilding, navy, energy, photographic equipment, aerial equipment, communication apparatus, electronic sensing devices, mobile electronic devices, cameras or any other needed working conditions.

Technical Parameter
  • Model Number Code Ordering of JGX-0160D-2.2A:Jgx-1598d-428b Aluminum Wire Rope Shock Isolator Condition for Bearing Core Components 0
  • Structural Diagram of JGX-0160D-2.2A:Jgx-1598d-428b Aluminum Wire Rope Shock Isolator Condition for Bearing Core Components 1
  • Dimension of JGX-0160D-2.2A:Jgx-1598d-428b Aluminum Wire Rope Shock Isolator Condition for Bearing Core Components 2
  • Mounting Options of JGX-0160D-2.2A:Jgx-1598d-428b Aluminum Wire Rope Shock Isolator Condition for Bearing Core Components 3
  • Compression of JGX-0160D-2.2A:Jgx-1598d-428b Aluminum Wire Rope Shock Isolator Condition for Bearing Core Components 4
  • 45° Compression of JGX-0160D-2.2A:Jgx-1598d-428b Aluminum Wire Rope Shock Isolator Condition for Bearing Core Components 5
  • Shear/Roll of JGX-0160D-2.2A:Jgx-1598d-428b Aluminum Wire Rope Shock Isolator Condition for Bearing Core Components 6
Mounting Bars

Material of Mounting Bars *
   Stainless Steel or Aluminum can be selected

* Surface Treatment Selection of Aluminum Mounting Bars *

  • White Anodizing: The surface treatment to make the aluminum surface harder than itself. The color of the white anodized aluminum mounting bars keep the same color as the aluminum itself. It is the normal surface treatment of the aluminum mounting bars;
  • Hard Anodizing: The surface treatment to make the aluminum mounting bars much more harder than the white anodized way. The color of the hard anodized aluminum mounting bars is more darker than the white anodizing way. Special use for complex or special requirements of the working conditions of the using of wire rope isolators.
Characteristics

* Unique Characteristics of Xi'an Hoan's Vibration Isolators *

  • No creep or ageing.
  • High internal damping.
  • Very wide temperature range.
  • Wide variety of possible fittings.
  • Rapid and economical prototyping.
  • Extremely rugged construction and long lifespan.
  • Excellent combined shock and vibration isolation.
  • Not affected by chemical agents, seawater, ozone, UV rays,...
Applications

* Applications of Wire Rope Isolators *



Applications

Typical Equipment

Protection From

Operational Advantages

Shipboard

Electronics, Computers,
Machinery

Explosive blast,
Inherent vibration, Storms

Long life, Maintenance-free,
Temperature extremes,
Corrosion resistance,
All axes protection

Rough Terrain Vehicles

Instrumentation, Generators,
Electronics

Rough terrain,
Poor road conditions,
Collision

Long life, Maintenance-free,
Temperature extremes, Ozone,
Radioactivity, UV Radiation

Aircraft

Electronics, Computers

High-G maneuvering,
Hard landings, Turbulent air

Temperature and altitude extremes, Lightweight

Shipping Containers

Optics, Instruments, Missiles, Electronics

Transit, Handling drop,

Loading/Unloading

Long life, Maintenance-free,

Exposure to moisture, Repeated use

Industrial Equipment



Centrifuge, Dryers, Pumps

Unbalanced dynamic loads,

Fluid hammer, Inherent vibration, Foundation weakness

Long life, Maintenance-free,

Corrosive environments

Ordnance Equipment

Missile launchers, Tank

artillery, Computer controls, Electronics

Rough terrain, Railroad humping, Transit

Maintenance-free, Temperature extremes, Nearby blast

Medical Equipment

Mechanical equipment

necessary for patient care

Vibration from moving parts, Mobile carts-Transport shock

Maintenance-free, No out gassing, Can be sterilized

Chimneys

Chimneys, Scrubbers,

Measuring devices

Wind causing resonant

frequencies, Stack gas causing turbulence near scrubber, etc.

Maintenance-free, Temperature extremes, Corrosive environments



* Applications Show *

Jgx-1598d-428b Aluminum Wire Rope Shock Isolator Condition for Bearing Core Components 7



Jgx-1598d-428b Aluminum Wire Rope Shock Isolator Condition for Bearing Core Components 8



Jgx-1598d-428b Aluminum Wire Rope Shock Isolator Condition for Bearing Core Components 9



Jgx-1598d-428b Aluminum Wire Rope Shock Isolator Condition for Bearing Core Components 10



Jgx-1598d-428b Aluminum Wire Rope Shock Isolator Condition for Bearing Core Components 11



Jgx-1598d-428b Aluminum Wire Rope Shock Isolator Condition for Bearing Core Components 12
