Name: Stainless Steel Wire Rope Vibration Isolator 2kg Load Capacity
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JMZ-1-2.0A
Availability: InStock

Home > products > Spring Isolator >

Stainless Steel Wire Rope Vibration Isolator 2kg Load Capacity

stainless steel wire rope isolator

wire rope vibration isolator 2kg

vibration isolator with load capacity

Place of Origin:

China

Brand Name:

Hoan

Model Number:

JMZ-1-2.0A

Request A Quote

Stainless Steel Wire Rope Vibration Isolator 2kg Load Capacity

Product Details

Material:

Stainless Steel

Design Style:

Industrial

After Warranty Service:

Online Support

Operating Temperature:

-40 To 80 Degrees Celsius

Corrosion Resistance:

High

Installation Method:

Screw Mounting

Marketing Type:

Hot Product 2025

Shock Resistance:

Strong

Mounting Orientation:

Vertical

Structure:

Helical

Installation Type:

Horizontal/Vertical

Construction:

Braided Wire Rope

Usage:

Vibration Isolation

Highlight:

stainless steel wire rope isolator

wire rope vibration isolator 2kg

vibration isolator with load capacity

Payment & Shipping Terms

Minimum Order Quantity

Payment Terms

L/C,D/A,D/P,T/T,Western Union,MoneyGram

JMZ-1-3.5A Adjustable Vibration Isolator for HVAC Equipment, 3.5kg Load

Get Best Price

Stainless Steel Wire Rope Vibration Isolator 2kg Load Capacity

Get Best Price

JMZ-1-1.5A Wire Rope Vibration Isolator 44mm for Industrial Engine Mounts

Get Best Price

JMZ-1-1.0A Friction Damping Vibration Isolator 1.0KG Load Capacity

Get Best Price

86-29-88292913

Contact Now

Product Description

JMZ-1-2.0A Wire Rope Vibration Isolator for Precision Equipment Protection in Industrial Environments

Product Description

JMZ-1-2.0A Stainless Steel Wire Rope Vibration Isolator with 2kg Load Capacity provides precision equipment protection in industrial environments, manufacturing facilities, laboratories, and high-end communications applications. Developed by Xi'an Hoan Microwave Co., Ltd., this solution effectively reduces vibrations in sensitive environments.

Key Technology

Unlike traditional spring or rubber vibration isolators, the JMZ series features a unique friction damping mechanism. Its precision friction pair structure efficiently converts vibration energy into thermal energy, providing exceptional suppression of vibrations—particularly low-frequency vibrations—without requiring power or complex maintenance.

Technical Specifications

Model	Nominal Load (kg)	B	A±0.2	H	h±0.5	T	d	d1	D
JMZ-1-1.0A	1.0	44	35	50	36	SW14	M5-7H	5.1～5.4	39.5
JMZ-1-1.5A	1.5	Same as JMZ-1-1.0A
JMZ-1-2.0A	2.0	Same as JMZ-1-1.0A
JMZ-1-3.0A	3.0	Same as JMZ-1-1.0A
JMZ-1-3.5A	3.5	Same as JMZ-1-1.0A

Performance Data

Model	Pz Nominal Load (KG)	Pz Max Deflection (mm)	Vibration (Kv)	Shock (Ks)	Resonant Frequency (Hz)	Working Temperature(℃)
JMZ-1-1.0A	1.0	3±1.5	≤3.5	30g/11ms	＜15	-65～+120
JMZ-1-1.5A	1.5	Same as JMZ-1-1.0A
JMZ-1-2.0A	2.0	2±1.5	Same as JMZ-1-1.0A
JMZ-1-3.0A	3.0	3±1.5	Same as JMZ-1-1.0A
JMZ-1-3.5A	3.5	Same as JMZ-1-1.0A

Unique Advantages

No creep or ageing
High internal damping
Very wide temperature range (-65℃ to +120℃)
Wide variety of possible fittings
Rapid and economical prototyping
Extremely rugged construction and long lifespan
Excellent combined shock and vibration isolation
Resistant to chemical agents, seawater, ozone, and UV rays

Application Examples
