Name: JMZ-TK1-7A Vibration Isolator with 4 inches Diameter for High-Frequency and Ultra-Low Frequency Vibration Control
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JMZ-TK1-7A
Availability: InStock

Home > Products > Spring Isolator >

JMZ-TK1-7A Vibration Isolator with 4 inches Diameter for High-Frequency and Ultra-Low Frequency Vibration Control

4 inches Diameter Vibration Isolator

High-Frequency Vibration Control Spring Isolator

Ultra-Low Frequency Vibration Control JMZ-TK Series

Place of Origin:

China

Brand Name:

Hoan

Model Number:

JMZ-TK1-7A

Request A Quote

Product Details

Color:

Silver

Isolation Efficiency:

95%

Applications:

Industrial Engine Mounts

Applicable Industries:

Energy & Mining

Structure:

Helical

Warranty:

1 Year

Durability:

Long-lasting

Dimensions:

Various Sizes Available

Shock Resistance:

Strong

Resilience:

High

Mounting Type:

Screw-In

Diameter:

4 Inches

Showroom Location:

None

Highlight:

4 inches Diameter Vibration Isolator

High-Frequency Vibration Control Spring Isolator

Ultra-Low Frequency Vibration Control JMZ-TK Series

Payment & Shipping Terms

Minimum Order Quantity

Payment Terms

L/C,D/A,D/P,T/T,Western Union,MoneyGram

Anti Vibration Spring Isolator Mount Air Conditioner Compressor HVAC Systems 800kg-900kg

Get Best Price

Spring Vibration Isolators For Fans Anti-Vibration Shock Absorber 1000kg-3300kg

Get Best Price

JMZ-TK-8A Rubber Shock Absorber For Stable And Accurate Missile Launches In Military Defense

Get Best Price

Video

Innovative Vibration Damping Solution JMZ-TK-6A Rubber Shock Absorber from Xi an Hoan Microwave Co. Ltd

Get Best Price

86-29-88292913

Contact Now

Product Description

JMZ-TK1-7A The Ultimate Vibration Isolator for High-Frequency and Ultra-Low Frequency Vibration Control in Scientific Research

JMZ-TK Series

Raising the Precision Ceiling of Scientific Research: The Value of JMZ-TK in Precision Measuring Instruments

In cutting-edge scientific research, measurement precision often determines the upper limit of new discoveries. Equipment such as scanning electron microscopes (SEM), atomic force microscopes (AFM), lithography machines, and gravitational wave detection devices are sensitive to environmental vibrations at the nanometer or even picometer level. The JMZ-TK series vibration isolators from Xi'an Hoan Microwave are precisely "ultra-quiet platforms" tailor-made for these cutting-edge scientific research instruments that pursue extreme precision.

The requirements for vibration isolation systems in these instruments are extremely stringent: they must not only isolate medium-to-high frequency vibrations, but also effectively address ultra-low frequency (<1Hz) ground microtremor noise. The JMZ-TK series perfectly meets this challenge through the combination of its low natural frequency design and high damping characteristics.

Combating Ground Microtremors: Through optimized design, its vertical natural frequency can be as low as 3-5Hz or even lower, enabling effective isolation of the main frequency band (1-20Hz) of ground microtremors.
Suppressing Internal Microvibrations: Microvibrations are also generated by internal components of high-precision instruments, such as scanning mechanisms and vacuum pumps. The high damping of JMZ-TK can quickly attenuate the transmission of these internal vibrations, preventing resonance from forming inside the instrument structure and interfering with measurement signals.

When researchers place samples under an electron microscope to observe atomic structures, or when a lithography machine etches nanoscale circuits on a silicon wafer, the JMZ-TK builds a nearly absolute static reference frame beneath the equipment. It eliminates image blurring, measurement drift, and circuit jagged edges caused by vibrations, directly improving the equipment's ultimate resolution and repeat measurement precision. It can be said that the JMZ-TK series is an unsung hero that helps scientists explore the unknown and expand the boundaries of human cognition.

Structural Dimension Diagram

Model	Installation dimensions(mm)	Overall dimensions(mm)
JMZ-TK1-25A/40A/50A	B: 63	A: 78
JMZ-TK1-25A/40A/50A	M: 12	C: 20

Technical Parameter Table

Model	Nominal Load (N)	Load Range (N)	Natural Frequency fn≤(Hz)	Loading Working Height H0±1(mm)	Maximum Vibration Transmissibility	Impact Resistance Test	Service Life (year)
JMZ-TK-2.5A	25	20～30	33	42	3	100g	10
JMZ-TK-4A	40	30～50
JMZ-TK-5A	50	40～60
JMZ-TK-6A	60	50～70
JMZ-TK-7A	70	60～80
JMZ-TK-8A	80	70～90
