Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber

Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber

  • Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber
  • Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber
  • Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber
  • Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber
  • Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber
  • Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber
Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber
Product Details:
Certification: ISO9001:2015
Payment & Shipping Terms:
Minimum Order Quantity: 4 pieces
Price: $61.27/pieces 4-199 pieces
Packaging Details: Standard export packing or as per customers' requirements.
Contact Now
Detailed Product Description
Condition: New Type: SHOCK ABSORBER
Material: Stainless Steel Or Aluminum, Stainless Steel Or Aluminum Applicable Industries: Energy & Mining
Weight (KG): 0.5 Showroom Location: None
Video Outgoing-inspection: Not Available Machinery Test Report: Not Available
Marketing Type: New Product 2020 Model: JGX-0648D-30A
Warranty: 1 Year Core Components: Bearing
Application: Launcher, Ship Construction
Highlight:

Wire rope anti vibration mount

,

Anti Vibration Wire Rope Mounts

,

Wire Rope Mounts Equipment

Customized Equipment Ship Construction Vibration Shock Control JGX-0648D-30A Shock Absorber

Product Description

Xi’an Hoan’s  extensive range of shock absorbers and elastomeric shock mounts, most equipment can be suspended successfully. Examples of common applications are electronic boxes, computers, monitors, radar units and similar. To use the correct equipment for the particular stress of  your case, Hoan’s engineers performs the correct shock calculations.



JGX-0648D-30A is the new designed 8 loops 6.4mm diameter model with max static load of 30kg, especially used in any instruments or systems for noise attenuation. With stainless steel material, this model has perfect performance of water-proof, anticorrosion as well as durability.



Nowadays, the JGX-0648 series shock absorbes are widely used in the field of shipbuilding, rail, highway transportation, shipborne, navy, photographic equipment, aerial equipment, communication apparatus, electronic sensing devices, mobile electronic devices, cameras or any other needed working conditions.

Technical Parameter
  • Model Number Code Ordering of JGX-0648D-30A:Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber 0
  • Structural Diagram of JGX-0648D-30A:Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber 1
  • Dimension of JGX-0648D-30A:Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber 2
  • Mounting Options of JGX-0648D-30A:Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber 3
  • Compression of JGX-0648D-30A:Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber 4
  • 45° Compression of JGX-0648D-30A:Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber 5
  • Shear/Roll of JGX-0648D-30A:Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber 6
Mounting Bars

Material of Mounting Bars *
   Stainless Steel or Aluminum can be selected

* Surface Treatment Selection of Aluminum Mounting Bars *

  • White Anodizing: The surface treatment to make the aluminum surface harder than itself. The color of the white anodized aluminum mounting bars keep the same color as the aluminum itself. It is the normal surface treatment of the aluminum mounting bars;
  • Hard Anodizing: The surface treatment to make the aluminum mounting bars much more harder than the white anodized way. The color of the hard anodized aluminum mounting bars is more darker than the white anodizing way. Special use for complex or special requirements of the working conditions of the using of wire rope isolators.
Characteristics

* Unique Characteristics of Xi'an Hoan's Vibration Isolators *

  • No creep or ageing.
  • High internal damping.
  • Very wide temperature range.
  • Wide variety of possible fittings.
  • Rapid and economical prototyping.
  • Extremely rugged construction and long lifespan.
  • Excellent combined shock and vibration isolation.
  • Not affected by chemical agents, seawater, ozone, UV rays,...
Applications

* Applications of Vibration Isolators *



Applications

Typical Equipment

Protection From

Operational Advantages

Shipboard

Electronics, Computers,
Machinery

Explosive blast,
Inherent vibration, Storms

Long life, Maintenance-free,
Temperature extremes,
Corrosion resistance,
All axes protection

Rough Terrain Vehicles

Instrumentation, Generators,
Electronics

Rough terrain,
Poor road conditions,
Collision

Long life, Maintenance-free,
Temperature extremes, Ozone,
Radioactivity, UV Radiation

Aircraft

Electronics, Computers

High-G maneuvering,
Hard landings, Turbulent air

Temperature and altitude extremes, Lightweight

Shipping Containers

Optics, Instruments, Missiles, Electronics

Transit, Handling drop,

Loading/Unloading

Long life, Maintenance-free,

Exposure to moisture, Repeated use

Industrial Equipment



Centrifuge, Dryers, Pumps

Unbalanced dynamic loads,

Fluid hammer, Inherent vibration, Foundation weakness

Long life, Maintenance-free,

Corrosive environments

Ordnance Equipment

Missile launchers, Tank

artillery, Computer controls, Electronics

Rough terrain, Railroad humping, Transit

Maintenance-free, Temperature extremes, Nearby blast

Medical Equipment

Mechanical equipment

necessary for patient care

Vibration from moving parts, Mobile carts-Transport shock

Maintenance-free, No out gassing, Can be sterilized

Chimneys

Chimneys, Scrubbers,

Measuring devices

Wind causing resonant

frequencies, Stack gas causing turbulence near scrubber, etc.

Maintenance-free, Temperature extremes, Corrosive environments



* Applications Show *

Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber 7



Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber 8



Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber 9



Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber 10



Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber 11



Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber 12



Anti Vibration Wire Rope Mounts Equipment Ship Construction Vibration Shock Absorber 13
