Product Details:
Brand Name: Hoan
Payment & Shipping Terms:
Minimum Order Quantity: 4 pieces
Price: $447.00/pieces 4-199 pieces
Contact Now
Detailed Product Description
Condition: New Type: SHOCK ABSORBER
Applicable Industries: Building Material Shops, Energy & Mining Weight (KG): 0.5
Showroom Location: None Video Outgoing-inspection: Not Available
Machinery Test Report: Provided Marketing Type: New Product 2020
Warranty: 1 Year Core Components: Gear

Product Description

Xi’an Hoan’s extensive range of vibration isolators and elastomeric shock mounts, most equipment can be suspended successfully. Examples of common applications are electronic boxes, computers, monitors, radar units and similar. To use the correct equipment for the particular stress of your case, Hoan’s engineers performs the correct shock calculations.



The spring function is created by the elasticity inherent in the flexing of a cable preformed into a loop. The damping function is the result of the relative friction between the cable’s individual wire and strands. The cables, which are made of stainless steel, had the characteristics of superb water-proof, corrosion resistance and steady in use.



The JGX-2228D-550B wire rope isolator is the kind type isolators from the family JGX-2228 series. The stainless steel cables and retaining bars provides amazing vibration isolation any time in use.



JGX-2228D-550B is the new designed 8 loops 22.2mm diameter wire rope isolators with max static load of 550kg, especially used in any instruments or systems for mechanical noise attenuation.



The JGX-2228D-550B model is now widely used in the field of vehicles, armored cars, missile, launcher, highway transportation, marine, shipbuilding, navy, energy, photographic equipment, aerial equipment, communication apparatus, electronic sensing devices, mobile electronic devices, cameras or any other needed working conditions.

Technical Parameter
  • Model Number Code Ordering of JGX-2228D-550B:Gear Missile Transformer Container Hydraulic Start Unit Engine Stand Vibration Shock Absorption 0
  • Structural Diagram of JGX-2228D-550B:Gear Missile Transformer Container Hydraulic Start Unit Engine Stand Vibration Shock Absorption 1
  • Dimension of JGX-2228D-550B:Gear Missile Transformer Container Hydraulic Start Unit Engine Stand Vibration Shock Absorption 2
  • Mounting Options of JGX-2228D-550B:Gear Missile Transformer Container Hydraulic Start Unit Engine Stand Vibration Shock Absorption 3
  • Compression of JGX-2228D-550B:Gear Missile Transformer Container Hydraulic Start Unit Engine Stand Vibration Shock Absorption 4
  • 45° Compression of JGX-2228D-550B:Gear Missile Transformer Container Hydraulic Start Unit Engine Stand Vibration Shock Absorption 5
  • Shear/Roll of JGX-2228D-550B:Gear Missile Transformer Container Hydraulic Start Unit Engine Stand Vibration Shock Absorption 6
Mounting Bars

Material of Mounting Bars *
   Stainless Steel or Aluminum can be selected

* Surface Treatment Selection of Aluminum Mounting Bars *

  • White Anodizing: The surface treatment to make the aluminum surface harder than itself. The color of the white anodized aluminum mounting bars keep the same color as the aluminum itself. It is the normal surface treatment of the aluminum mounting bars;
  • Hard Anodizing: The surface treatment to make the aluminum mounting bars much more harder than the white anodized way. The color of the hard anodized aluminum mounting bars is more darker than the white anodizing way. Special use for complex or special requirements of the working conditions of the using of wire rope isolators.
Characteristics

* Unique Characteristics of Xi'an Hoan's Vibration Isolators *

  • No creep or ageing.
  • High internal damping.
  • Very wide temperature range.
  • Wide variety of possible fittings.
  • Rapid and economical prototyping.
  • Extremely rugged construction and long lifespan.
  • Excellent combined shock and vibration isolation.
  • Not affected by chemical agents, seawater, ozone, UV rays,...
Applications

* Applications of Wire Rope Isolators *



Applications

Typical Equipment

Protection From

Operational Advantages

Shipboard

Electronics, Computers,
Machinery

Explosive blast,
Inherent vibration, Storms

Long life, Maintenance-free,
Temperature extremes,
Corrosion resistance,
All axes protection

Rough Terrain Vehicles

Instrumentation, Generators,
Electronics

Rough terrain,
Poor road conditions,
Collision

Long life, Maintenance-free,
Temperature extremes, Ozone,
Radioactivity, UV Radiation

Aircraft

Electronics, Computers

High-G maneuvering,
Hard landings, Turbulent air

Temperature and altitude extremes, Lightweight

Shipping Containers

Optics, Instruments, Missiles, Electronics

Transit, Handling drop,

Loading/Unloading

Long life, Maintenance-free,

Exposure to moisture, Repeated use

Industrial Equipment



Centrifuge, Dryers, Pumps

Unbalanced dynamic loads,

Fluid hammer, Inherent vibration, Foundation weakness

Long life, Maintenance-free,

Corrosive environments

Ordnance Equipment

Missile launchers, Tank

artillery, Computer controls, Electronics

Rough terrain, Railroad humping, Transit

Maintenance-free, Temperature extremes, Nearby blast

Medical Equipment

Mechanical equipment

necessary for patient care

Vibration from moving parts, Mobile carts-Transport shock

Maintenance-free, No out gassing, Can be sterilized

Chimneys

Chimneys, Scrubbers,

Measuring devices

Wind causing resonant

frequencies, Stack gas causing turbulence near scrubber, etc.

Maintenance-free, Temperature extremes, Corrosive environments



* Applications Show *

Gear Missile Transformer Container Hydraulic Start Unit Engine Stand Vibration Shock Absorption 7



Gear Missile Transformer Container Hydraulic Start Unit Engine Stand Vibration Shock Absorption 8



Gear Missile Transformer Container Hydraulic Start Unit Engine Stand Vibration Shock Absorption 9



Gear Missile Transformer Container Hydraulic Start Unit Engine Stand Vibration Shock Absorption 10



Gear Missile Transformer Container Hydraulic Start Unit Engine Stand Vibration Shock Absorption 11



Gear Missile Transformer Container Hydraulic Start Unit Engine Stand Vibration Shock Absorption 12



Gear Missile Transformer Container Hydraulic Start Unit Engine Stand Vibration Shock Absorption 13
