Place of Origin:
china
Model Number:
GX
Product Structure Diagram:
SIZE PARAMETER:
| Model | L(mm) | A±0.3 | H±1.5 | W±1.5 | d | wire rope loops | Rubber pad size |
| GX-10A(N) | 55 | 49 | 21 | 26 | M3-7H | 6 | 46*12*8 |
| GX-20A(N) | 84 | 68 | 29 | 35 | M5-7H | 6 | 62*14*10 |
| GX-30A(N) | 113 | 97 | 32.5 | 40 | M5-7H | 8 | 91*14*15 |
| GX-40A(N) | 113 | 97 | 32.5 | 40 | M5-7H | 8 | 91*14*15 |
| GX-50A(N) | 113 | 97 | 33 | 40 | M5-7H | 10 | 91*14*15 |
| GX-60A(N) | 133 | 117 | 31 | 40 | M5-7H | 10 | 108*14*1 |
Technical Parameters:
| Technical Parameter | model | |
| GX-A | GX-AN | |
| Pz Nominal Load(N) | 10～60 | |
| Deflection | 压下 | |
| Resonance Magnification | ≤4 | |
| High Frequency Efficiency | ≥95 | |
| Working Temperature | -55～+125 | |
| Shock(Ks) | 30g/11ms | 100g/6ms |
| G Peak Respones G | ≤3.5km/s2 | |
Vibration&Shock Resistance Curve Chart:
characteristic:
1. Vibration absorption capacity: Due to the use of materials such as steel wire ropes and rubber pads, GX can effectively absorb the vibration energy of building structures caused by earthquakes or wind vibrations, reducing the impact on buildings.
2. Improvement of seismic performance: By reducing the amplitude of vibration, GX enhances the seismic resistance of buildings, making them more capable of withstanding natural disasters such as earthquakes.
3. Comfort enhancement: reduces the vibration of the building structure, thereby improving the comfort inside the building, making the living or working environment more stable and safe.
4. Reliability and Durability: Adopting durable materials and structural design, GX has high reliability and durability, effectively protecting the building structure from external vibrations in the long run.
Application:
1. High rise buildings
2. Bridges
3. Industrial facilities
