Name: Integrate JGX-1278A-370A Wire Rope Vibration Isolator for Improved Equipment Lifespan and Stability
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JGX-1278A-370A
Availability: InStock

Home > Products > Wire Rope Vibration Isolator >

Integrate JGX-1278A-370A Wire Rope Vibration Isolator for Improved Equipment Lifespan and Stability

Wire Rope Vibration Isolator for Lifespan

Wire Rope Vibration Isolator for Stability

Place of Origin:

China

Brand Name:

Hoan

Model Number:

JGX-1278A-370A

Request A Quote

Product Details

Features:

High Load Capacity, Low Resonant Frequency, Durable

Material:

Stainless Steel

Relative Product:

Backdraft Damper

Max Static Load:

20-47N(2kg-4.8Kg)

Natural Frequency:

10 Hz

Characteristic:

Wide Working Frequency, Long Life Span

Packing:

Standard Packing

Temperature Range:

-40°C To 100°C

After Warranty Service:

Online Support

Shock Rsistance:

30g/11ms

High:

216mm

Product Load Capacity:

Customizable

Vibration Isolation Type:

Passive

Isolation Frequency Range:

5Hz To 100Hz

Highlight:

Wire Rope Vibration Isolator for Lifespan

Wire Rope Vibration Isolator for Stability

Payment & Shipping Terms

Minimum Order Quantity

Payment Terms

L/C,D/A,D/P,T/T,Western Union,MoneyGram

JZP-3.2 High-Performance Prefabricated Vibration Isolator with 15Hz Resonance Frequency for Medical Instruments and Deep-Sea Exploration

Get Best Price

Video

Galvanized Steel Wire Rope Vibration Isolator with 5Hz to 100Hz Isolation Frequency for Multi-Directional Vibration Protection

Get Best Price

Video

JGX-0956A-104A Wire Rope Vibration Isolator All Metal Open Structure For Outdoor Scenarios

Get Best Price

Video

JGX-1598A-557A Wide-Frequency "Silencing" Capability for High-End Optical Platforms and Semiconductor Manufacturing Equipment

Get Best Price

Contact Now

Product Description

JGX-1278A Series

Xi'an Hoan Microwave practices the concept of green manufacturing. The JGX-1278A series adopts lead-free welding processes and recyclable materials, reducing the product's carbon footprint by 40% compared with traditional processes. Its long-life design reduces the frequency of equipment replacement, indirectly lowering resource consumption. The company has established a reverse logistics system, enabling non-destructive disassembly and material recycling of decommissioned products, with a metal recovery rate of 95%. This full-life-cycle environmental protection practice has made the JGX-1278A series a model of green industrial equipment.

With continuous technological innovation, Xi'an Hoan Microwave has made the JGX-1278A series steel wire rope vibration isolators a benchmark product for anti-seismic protection of high-end equipment. Its full-chain technological advantages, from material research and development to intelligent manufacturing, not only meet the stringent requirements of , aerospace and other fields, but also provide reliable solutions for equipment upgrading in the Industry 4.0 era. With the in-depth integration of intelligent sensor technology, this series of products is moving towards the direction of intelligent condition monitoring and adaptive adjustment, leading new trends in industry development.

Integrate JGX-1278A-370A Wire Rope Vibration Isolator for Improved Equipment Lifespan and Stability 0

Mounting Options

Integrate JGX-1278A-370A Wire Rope Vibration Isolator for Improved Equipment Lifespan and Stability 1

SIZE PARAMETER:

Model	“H”±3.30	“W”	Unit weight	Mounting options	Thru hole (mm)	Thread (mm)	C'sink
JGX-1278D-370B	76	92	1.81	A,B,C,D,E,S	∅9.0+0.13 -0.38	M8×1.25	90
JGX-1278D-310B	83	102	1.91
JGX-1278D-292B	89	105	2.00
JGX-1278D-235B	95	121	2.22
JGX-1278D-199B	108	133	2.40
JGX-1278D-176B	124	144	2.70
JGX-1278D-154B	137	156	2.90
JGX-1278D-122B	155	180	3.09

Static-Load Curve

Integrate JGX-1278A-370A Wire Rope Vibration Isolator for Improved Equipment Lifespan and Stability 2

No	Model	Max Static Load (kg)	Max Deflection (mm)	Kv(Vibration) (KN/m)	Ks(Shock) (KN/m)
1	JGX-1278A-370A	370	32.0	954	471
2	JGX-1278A-310A	310	38.1	708	333
3	JGX-1278A-292A	292	43.2	613	278
4	JGX-1278A-235A	235	48.8	457	196
5	JGX-1278A-199A	199	59.9	340	137
6	JGX-1278A-176A	176	74.7	261	96
7	JGX-1278A-154A	154	85.9	207	74
8	JGX-1278A-122A	122	102.6	148	49

Integrate JGX-1278A-370A Wire Rope Vibration Isolator for Improved Equipment Lifespan and Stability 3

No	Model	Max Static Load (kg)	Max Deflection (mm)	Kv(Vibration) (KN/m)	Ks(Shock) (KN/m)
1	JGX-1278A-370A	263.2	44.7	539	236
2	JGX-1278A-310A	220.1	52.8	398	168
3	JGX-1278A-292A	208.8	61.0	349	138
4	JGX-1278A-235A	165.7	68.6	259	98
5	JGX-1278A-199A	143.0	84.8	193	68
6	JGX-1278A-176A	124.8	105.7	147	49
7	JGX-1278A-154A	109.0	121.9	117	37
8	JGX-1278A-122A	84.0	144.8	83	25

Integrate JGX-1278A-370A Wire Rope Vibration Isolator for Improved Equipment Lifespan and Stability 4

No	Model	Max Static Load (kg)	Max Deflection (mm)	Kv(Vibration) (KN/m)	Ks(Shock) (KN/m)
1	JGX-1278A-370A	299.6	33.0	294	294
2	JGX-1278A-310A	174.8	40.1	207	207
3	JGX-1278A-292A	158.9	45.2	173	173
4	JGX-1278A-235A	122.6	50.8	121	121
5	JGX-1278A-199A	81.7	56.9	81	81
6	JGX-1278A-176A	61.3	77.7	60	60
7	JGX-1278A-154A	45.4	90.9	46	46
8	JGX-1278A-122A	29.5	107.7	30	30

FAQ

Q : Are you trading company or manufacturer?
A: We are manufacturer of industrial workshop damping vibration and micro-vibration absorbing products with many year experience in China.

Q: How long is your delivery time?
A: If we have stock, we can delivery immeditary. If no stock, depends on QTY, but normally no more than 20 working days

Q: What's the weight and measurement for the product?
A: Different size with differenct amount, please contact us for details.

Q: Can the products be manufactuered by customer's requirement?
A: Yes, OEM service available

Q: What do you need to know for fast quotation?
A:I need your equipment weight, volume; Shock and vibration requirements of the equipment; We would appreciate these details on the application environment of the device

Q: Visting company is allowed or not?
A: Yes, we welcome customers visiting our company.We are located in Xi'an, Shaanxi, China
