JGX-2228A-550A The Ultimate Solution for Vibration Control in Cutting-Edge National Defense and Industrial Manufacturing

JGX-2228A Series

Cross-Domain Applications: Comprehensive Coverage from Cutting-Edge National Defense to Industrial Manufacturing

The modular design of JGX-2228A enables it to demonstrate unique value across multiple fields. In the national defense sector, this isolator has been applied to the fire control system of a new-type missile launch vehicle. By controlling the equipment's vibration amplitude within 0.1mm, it ensures that the pointing accuracy error of the radar antenna during off-road driving is less than 0.05 degrees, which is triple the performance of traditional rigid connection solutions. In the marine field, its impact resistance has been successfully utilized in the sonar array of a frigate. During underwater explosion impact tests, the equipment's response acceleration was reduced to 15g, effectively protecting the core components of precision sensors.

In industrial scenarios, the product addresses the problem of vibration transmission in large-scale equipment through flexible connection technology. After a petrochemical enterprise adopted JGX-2228A for its compressor unit, the vibration stress of the pipeline system was reduced by 60%. The supporting intelligent monitoring module (customizable) can feed back the isolator's health status in real time, extending the predictive maintenance cycle to twice that of traditional solutions. In the new energy sector, its resistance to high and low temperatures makes it perform excellently in wind power converters. When starting at -30℃, the temperature rise rate of the equipment is reduced by 30%, effectively prolonging the service life of power devices.

Notably, the lightweight design of JGX-2228A (weighing only 60% of traditional metal isolators) opens up new possibilities for aerospace applications. After a UAV-mounted radar system adopted this product, the overall weight of the machine was reduced by 12kg, while its anti-vibration performance was improved by 40%, enabling the UAV to maintain stable reconnaissance image quality even under level-6 wind conditions. Such cross-domain technological transfer capability reflects Xi'an Hoan Microwave's profound accumulation in the field of vibration isolation technology.

Dimension Parameter Table

Static-Load Curve

* Surface Treatment Selection of Aluminum Mounting Bars *

* White Anodizing: The surface treatment to make the aluminum surface harder than itself. The color of the white anodized aluminum mounting bars keep the same color as the aluminum itself. It is the normal surface treatment of the aluminum mounting bars;

* Hard Anodizing: The surface treatment to make the aluminum mounting bars much more harder than the white anodized way. The color of the hard anodized aluminum mounting bars is more darker than the white anodizing way. Special use for complex or special requirements of the working conditions of the using of wire rope isolators.

* Material of Mounting Bars *

Stainless Steel or Aluminum can be selected
