Name: JZP-15 Rubber Shock Absorber 15Kg Load Industrial Vibration Isolator
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JZP-15
Availability: InStock

Home > Products > Rubber Shock Absorber >

JZP-15 Rubber Shock Absorber 15Kg Load Industrial Vibration Isolator

Industrial Vibration Isolator Shock Absorber

JZP-15 Rubber Shock Absorber

15Kg Load Rubber Shock Absorber

Place of Origin:

China

Brand Name:

Hoan

Model Number:

JZP-15

Request A Quote

Product Details

Max Static Load:

15Kg

Vibration Frequency:

5-50Hz

Warranty:

1 Year

Width:

60mm

Package:

Plastic Bag, Cartons

Uv Resistance:

Strong

Shock Resistance:

40g/11ms

Durability:

High

Design Style:

Industrial

Maximum Load Capacity:

15kg

Highlight:

Industrial Vibration Isolator Shock Absorber

JZP-15 Rubber Shock Absorber

15Kg Load Rubber Shock Absorber

Payment & Shipping Terms

Minimum Order Quantity

Payment Terms

MoneyGram,Western Union,T/T,D/A,L/C,D/P

JZP-13.5-SC-SC1 Rubber Shock Absorber with Damping Ratio 0.5 1 Year Warranty and 60mm Length for Sustainable Manufacturing

Get Best Price

JZP-10.5-SC-SC1 Rubber Shock Absorber with 10Hz to 100Hz Frequency Range and -55 to +120 Working Temperature for Horizontal/Vertical Installation

Get Best Price

JZP-9.0-SC-SC1 Rubber Shock Absorber with Temperature Resistance Up to 100 Degrees Celsius 50mm Width and 30 Hz Resonance Frequency for Industrial Machinery

Get Best Price

JZP-7.5-SC-SC1 Friction Damping Vibration Isolator with Up to 90% Vibration Isolation M5 Mounting Thread Size and 50N/mm Axial Stiffness

Get Best Price

86-29-88292913

Contact Now

Product Description

JZP-15 Rubber Shock Absorber

The Perfect Combination of Vibration Isolation and Damping Technology

Product Specifications

Attribute	Value
Max Static Load	15Kg
Vibration Frequency	5-50Hz
Warranty	1 Year
Width	60mm
Package	Plastic Bag, Cartons
UV Resistance	Strong
Shock Resistance	40g/11ms
Durability	High
Design Style	Industrial
Maximum Load Capacity	15kg

JZP Series Advanced Vibration Control

Beyond simple vibration isolation, the JZP series integrates advanced damping technology to actively control harmful vibrations, protecting equipment during start-up, shutdown, and impact scenarios.

Performance Benefits

Improves positioning accuracy for optical platforms and scanning equipment
Protects sensitive electronic components by reducing vibration stress
Reduces noise radiation by suppressing shell vibrations
Enhances overall equipment reliability and extends service life

Dimension Parameters

Model	D	H	h	A	B	d1	MG	R
JZP	58	29	17	50	60	∅5.5	M6	5

Technical Parameters

Model	Pz Nominal Load (kg)	Deformation Displacement (mm)	Resonant Frequency (Hz)	Working Temperature (℃)	Shock (ks)	Peak Response G
JZP-2.5	2.5	≤0.3	35±3	-45～+65	100g/6ms	≤3.6Km/s2
JZP-3.2	3.2	Same specifications as JZP-2.5 with different load capacity
JZP-4.2	4.2	Same specifications as JZP-2.5 with different load capacity
JZP-5.2	5.2	Same specifications as JZP-2.5 with different load capacity
JZP-6.0	6.0	Same specifications as JZP-2.5 with different load capacity
JZP-7.0	7.0	Same specifications as JZP-2.5 with different load capacity
JZP-7.5	7.5	Same specifications as JZP-2.5 with different load capacity
JZP-8.5	8.5	Same specifications as JZP-2.5 with different load capacity
JZP-10.5	10.5	Same specifications as JZP-2.5 with different load capacity
JZP-13.5	13.5	Same specifications as JZP-2.5 with different load capacity
JZP-15	15	Same specifications as JZP-2.5 with different load capacity

Performance Characteristics

Unique Product Features

No creep or ageing
High internal damping
Very wide temperature range (-45℃ to +65℃)
Wide variety of possible fittings
Rapid and economical prototyping
Extremely rugged construction and long lifespan
Excellent combined shock and vibration isolation
Resistant to chemical agents, seawater, ozone, and UV rays

Customer Applications
