JT-QTF-1501-KFD Customized Bandpass Filter with 50Ω Impedance and N-KFD Interface

JT-QTF-1501-KFD Customized Bandpass Filter with 50Ω Impedance and N-KFD Interface

  • JT-QTF-1501-KFD Customized Bandpass Filter with 50Ω Impedance and N-KFD Interface
JT-QTF-1501-KFD Customized Bandpass Filter with 50Ω Impedance and N-KFD Interface
Product Details:
Payment & Shipping Terms:
Minimum Order Quantity: 1
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Contact Now
Detailed Product Description
Passband Frequency: 1472MHz~1530MHz Insertion Loss: ≤0.6dB
VSWR: ≤1.3 Rejection: ≥20dB@1442MHz,≥20dB@1560MHz, ≥75dB@1352MHz,≥75dB@1650MHz
Impedance: 50Ω Interface Type: N-KFD
Operating Temperature: -55℃~85℃ External Dimensions: 160×70×25(mm)
Weight: 450g
Highlight:

N-KFD Interface Bandpass Filter

,

50Ω Impedance Bandpass Filter

,

Customized Bandpass Filter

Summary

JT-QTF-1501-KFD cavity filter is a bandpass filter used to select signal frequency bands, limit input signal bandwidth, suppress noise, and improve signal to noise ratio.

Mainly used in military or civilian communication systems to improve communication quality and suppress interference in this frequency band.



Characteristic

Low insertion loss, high reliability, and strong environmental adaptability.

JT-QTF-1501-KFD Customized Bandpass Filter with 50Ω Impedance and N-KFD Interface 0

Main parameter

passband frequency 1472MHz~1530MHz
insertion loss ≤0.6dB
rejection

≥20dB@1442MHz,≥20dB@1560MHz,

≥75dB@1352MHz,≥75dB@1650MHz

VSWR ≤1.3
impedance 50Ω
interface type N-KFD
operating temperature -55℃~85℃
external dimensions 160×70×25(mm)
weight 450g
